Trepanning Touch Screen
Specializing in sectors such as gaming, kiosks, hospitality, POS, EV charging, retail, and transportation, Touch Pro offers tailor-made touch-screen displays. The company's in-house R&D team prides itself on customizing touch screen sizes and coding requirements to meet every client's unique needs.
Trepanning
ZD-185MT1C-V1
Resolution 1366×768
Contrast 1000∶1
Brightness 250cd/m2
Driver Board A/D Board
Key Functions Support
Operating Temperature 0°-60°
Exterior Dimensions
Liquid Crystal Model M185XTN01.2
ZD-215MT5C-V1
Resolution 1920×1080
Contrast 3000∶1
Brightness 250cd/m2
Driver Board A/D Board
Key Functions Support
Operating Temperature 0°-60°
Exterior Dimensions
Liquid Crystal Model T215HVN01.1
ZD-236MT2C-V1
Resolution 1920×1080
Contrast 1000∶1
Brightness 250cd/m2
Bonding Method KT
Driver Board 2513V2.1
Key Functions Not Support
Operating Temperature 0°-60°
Exterior Dimensions
Liquid Crystal Model
HR236WU1-300(BOE)
ZD-270MT2C-V1
Resolution 1920×1080
Contrast 3000∶1
Brightness 300cd/m2
Bonding Method KT
Driver Board 2513V2.1
Key Functions Not Support
Operating Temperature 0°-60°
Exterior Dimensions
Liquid Crystal Model M270HVN02.0
ZD-315MN1G-V3
Resolution 1920×1080
Contrast 1000∶1
Brightness 300cd/m2
Bonding Method KT
Driver Board 2513V2.1
Key Functions Not Support
Operating Temperature 0°-60°
Exterior Dimensions
Liquid Crystal Model M315DJJ-K30
ZD-315MT1C-V3
Resolution 1920×1080
Contrast 1000∶1
Brightness 300cd/m2
Bonding Method KT
Driver Board 2513V2.1
Key Functions Not Support
Operating Temperature 0°-60°
Exterior Dimensions
Liquid Crystal Model M315DJJ-K30
Trepanning-Style 1
ZD-150MT1R-V1
Resolution 1024×768
Contrast 600∶1
Brightness 250cd/m2
Bonding Method N/A
Driver Board A/D Board
Key Functions Support
Operating Temperature 0°-60°
Exterior Dimensions
Liquid Crystal Model TM150TDSG70
ZD-150MT1R-V2
Resolution 1024×768
Contrast 600∶1
Brightness 250cd/m2
Bonding Method N/A
Driver Board A/D Board
Key Functions Support
Operating Temperature 0°-60°
Exterior Dimensions
Liquid Crystal Model TM150TDSG70
ZD-156MT1C-V2
Resolution 1920×1080
Contrast 1000∶1
Brightness 900cd/m2
Bonding Method N/A
Driver Board A/D Board
Key Functions Support
Operating Temperature 0°-60°
Exterior Dimensions
Liquid Crystal Model G156HAN02.1
ZD-170MT10C-V1
Resolution 1280×1024
Contrast 1000∶1
Brightness 450cd/m2
Bonding Method N/A
Driver Board A/D Board
Bonding Method KT/QT
Key Functions Support
Operating Temperature 0°-60°
Exterior Dimensions
ZD-185MT2C-V2
Resolution 1920×1080
Contrast 1000∶1
Brightness 300cd/m2
Bonding Method N/A
Driver Board A/D Board
Key Functions Support
Operating Temperature 0°-60°
Exterior Dimensions
ZD-185MT2C-V3
Resolution 1920×1080
Contrast 1000∶1
Brightness 450cd/m2
Bonding Method KT/QT
Driver Board 2513V2.1
Key Functions Support
Operating Temperature 0°-60°
Exterior Dimensions
Liquid Crystal Model
GV185FHM-N10
ZD-190MN1G-V1
Resolution 1280×1024
Contrast 1000∶1
Brightness 1500cd/m2
Bonding Method KT/QT
Driver Board 2513V2.1
Key Functions Support
Operating Temperature 0°-60°
Exterior Dimensions
Liquid Crystal Model
G190ETN01.4(AUO:G190ETN01.4-DE15)+Light-sensitive
ZD-190MT6C-V1
Resolution 1280×1024
Contrast 1000∶1
Brightness 1000cd/m2
Bonding Method KT/QT
Driver Board 2513V2.1
Key Functions Support
Operating Temperature 0°-60°
Exterior Dimensions
Liquid Crystal Model
G190ETN01.4(AUO)+1000Brightness
ZD-215MN1N-V2
Resolution 1920×1080
Contrast 1000∶1
Brightness 1000cd/m2
Bonding Method KT/QT
Driver Board 2513V2.1
Key Functions Support
Operating Temperature 0°-60°
Exterior Dimensions
Liquid Crystal Model
HR215WU1-120
+1000Brightness+Dual brightening plate
ZD-215MN1N-V3
Resolution 1920×1080
Contrast 3000∶1
Brightness 450cd/m2
Bonding Method KT/QT
Driver Board 2513V2.1
Key Functions Support
Operating Temperature 0°-60°
Exterior Dimensions
Liquid Crystal Model
T215HVN01.1
ZD-238MT5C-V1-01
Resolution 1920×1080
Contrast 3000∶1
Brightness 250cd/m2
Bonding Method KT/QT
Driver Board 2513V2.1
Key Functions Support
Operating Temperature 0°-60°
Exterior Dimensions
Liquid Crystal Model
MV238FHM-K11
ZD-238MN1G-V1
Resolution 1920×1080
Contrast 1000∶1
Brightness 850cd/m2
Bonding Method KT/QT
Driver Board 2513V2.1
Key Functions Support
Operating Temperature 0°-60°
Exterior Dimensions
Liquid Crystal Model
MV238FHM-K11
Trepanning-Style 2
ZD-101MT3C-V1
Resolution 1280×800
Contrast 1300∶1
Brightness 900cd/m2
Bonding Method KT/QT
Driver Board 2513V2.1
Key Functions Support
Operating Temperature 0°-60°
Exterior Dimensions
Liquid Crystal Model
G101EVN03.1
ZD-101MT5C-V1
Resolution 1280×800
Contrast 1300∶1
Brightness 500cd/m2
Bonding Method KT/QT
Driver Board 2513V2.1
Key Functions Support
Operating Temperature 0°-60°
Exterior Dimensions
Liquid Crystal Model
G101EVN01.3
ZD-101MT5C-V2
Resolution 1280×800
Contrast 1300∶1
Brightness 900cd/m2
Bonding Method KT/QT
Driver Board 2513V2.1
Key Functions Support
Operating Temperature 0°-60°
Exterior Dimensions
Liquid Crystal Model
G101EVN01.3
ZD-101MT7C-V1
Resolution 1280×800
Contrast 900∶1
Brightness 950cd/m2
Bonding Method KT/QT
Driver Board 2513V2.1
Key Functions Support
Operating Temperature 0°-60°
Exterior Dimensions
Liquid Crystal Model
EV101WXM-N80
+1000Brightness+Light-Sensitive
ZD-150MT4C-V1
Resolution 1024×768
Contrast 600∶1
Brightness 300cd/m2
Bonding Method KT/QT
Driver Board 2513V2.1
Key Functions Support
Operating Temperature 0°-60°
Exterior Dimensions
Liquid Crystal Model
TM150TDSG70
ZD-150MT4C-V2
Resolution 1024×768
Contrast 1000∶1
Brightness 600cd/m2
Bonding Method KT/QT
Driver Board 2513V2.1
Key Functions Support
Operating Temperature 0°-60°
Exterior Dimensions
Liquid Crystal Model
TM150TDSG70
ZD-156MT1C-V3
Resolution 1920×1080
Contrast 800∶1
Brightness 200cd/m2
Bonding Method KT/QT
Driver Board 2513V2.1
Key Functions Support
Operating Temperature 0°-60°
Exterior Dimensions
Liquid Crystal Model
NV156FHM-N42
ZD-170MT5C-V1
Resolution 1280×1024
Contrast 1000∶1
Brightness 250cd/m2
Bonding Method KT/QT
Driver Board 2513V2.1
Key Functions Support
Operating Temperature 0°-60°
Exterior Dimensions
Liquid Crystal Model
M170ETN01.1
ZD-170MT7C-V1
Resolution 1280×1024
Contrast 1000∶1
Brightness 280cd/m2
Bonding Method KT/QT
Driver Board 2513V2.1
Key Functions Support
Operating Temperature 0°-60°
Exterior Dimensions
Liquid Crystal Model
M170ETN01.1
ZD-190MT7C-V1
Resolution 1280×1024
Contrast 1000∶1
Brightness 250cd/m2
Bonding Method KT/QT
Driver Board 2513V2.1
Key Functions Support
Operating Temperature 0°-60°
Exterior Dimensions
Liquid Crystal Model
M190ETN01.0
ZD-215MT3C-V1
Resolution 1920×1080
Contrast 3000∶1
Brightness 250cd/m2
Bonding Method KT/QT
Driver Board 2513V2.1
Key Functions Support
Operating Temperature 0°-60°
Exterior Dimensions
Liquid Crystal Model
T215HVN01.1(AUO)
ZD-236MT1C-V1
Resolution 1920×1080
Contrast 1000∶1
Brightness 250cd/m2
Bonding Method KT/QT
Driver Board 2513V2.1
Key Functions Support
Operating Temperature 0°-60°
Exterior Dimensions
Liquid Crystal Model
M236HGE-L20 Rev C5(CMO)
ZD-270MT1C-V1
Resolution 1920×1080
Contrast 3000∶1
Brightness 1500cd/m2
Bonding Method KT/QT
Driver Board 2513V2.1
Key Functions Support
Operating Temperature 0°-60°
Exterior Dimensions
Liquid Crystal Model
YZ270CD01-DE15(DC12V)
+1500Brightness+Light-sensitive
ZD-270MT1C-V2
Resolution 1920×1080
Contrast 3000∶1
Brightness 350cd/m2
Bonding Method KT/QT
Driver Board 2513V2.1
Key Functions Support
Operating Temperature 0°-60°
Exterior Dimensions
Liquid Crystal Model
M270HVN02.0
Trepanning-Style 3
ZD-101MT6C-V1
Resolution 1280×1024
Contrast 1300∶1
Brightness 350cd/m2
Bonding Method KT/QT
Driver Board 2513V2.1
Key Functions Support
Operating Temperature 0°-60°
Exterior Dimensions
Liquid Crystal Model
G101EVN01.3
ZD-101MT6C-V4
Resolution 1280×1024
Contrast 1300∶1
Brightness 350cd/m2
Bonding Method KT/QT
Driver Board 2513V2.1
Key Functions Support
Operating Temperature 0°-60°
Exterior Dimensions
Liquid Crystal Model
G101EVN01.3
ZD-121MT1C-V1
Resolution 1024×768
Contrast 700∶1
Brightness 430cd/m2
Bonding Method KT/QT
Driver Board 2513V2.1
Key Functions Support
Operating Temperature 0°-60°
Exterior Dimensions
ZD-121MT1C-V2
Resolution 1024×768
Contrast 800∶1
Brightness 980cd/m2
Bonding Method KT/QT
Driver Board 2513V2.1
Key Functions Support
Operating Temperature 0°-60°
Exterior Dimensions
Liquid Crystal Model
M121GNX2 R1(IVO)
ZD-150MT1C-V1
Resolution 1024×768
Contrast 700∶1
Brightness 850cd/m2
Bonding Method KT/QT
Driver Board 2513V2.1
Key Functions Support
Operating Temperature 0°-60°
Exterior Dimensions
Liquid Crystal Model
G150XTN06.2(AUO)
ZD-170MT6C-V1
Resolution 1280×1024
Contrast 1000∶1
Brightness 280cd/m2
Bonding Method KT/QT
Driver Board 2513V2.1
Key Functions Support
Operating Temperature 0°-60°
Exterior Dimensions
Liquid Crystal Model
M170ETN01.1
ZD-173MT1C-V1
Resolution 1920×1080
Contrast 600∶1
Brightness 300cd/m2
Bonding Method KT/QT
Driver Board 2513V2.1
Key Functions Support
Operating Temperature 0°-60°
Exterior Dimensions
Liquid Crystal Model
G173HW01 V0(AUO)
ZD-185MT1C-V1
Resolution 1024×768
Contrast 1000∶1
Brightness 250cd/m2
Bonding Method KT/QT
Driver Board 2513V2.1
Key Functions Support
Operating Temperature 0°-60°
Exterior Dimensions
Liquid Crystal Model
M185XTN01.2
ZD-195MN1N-V1
Resolution 1600×900
Contrast 1000∶1
Brightness 250cd/m2
Bonding Method KT/QT
Driver Board 2513V2.1
Key Functions Support
Operating Temperature 0°-60°
Exterior Dimensions
Liquid Crystal Model
LM195WD2-SLA1(LG)
ZD-215MN1N-V1
Resolution 1920×1080
Contrast 3000∶1
Brightness 250cd/m2
Bonding Method KT/QT
Driver Board 2513V2.1
Key Functions Support
Operating Temperature 0°-60°
Exterior Dimensions
Liquid Crystal Model
M215HJJ-L30(INNOLUX)
ZD-215MT5C-V1
Resolution 1920×1080
Contrast 3000∶1
Brightness 250cd/m2
Bonding Method KT/QT
Driver Board 2513V2.1
Key Functions Support
Operating Temperature 0°-60°
Exterior Dimensions
Liquid Crystal Model T215HVN01.1
ZD-236MT2C-V1
Resolution 1920×1080
Contrast 1000∶1
Brightness 250cd/m2
Bonding Method KT/QT
Driver Board 2513V2.1
Key Functions Support
Operating Temperature 0°-60°
Exterior Dimensions
Liquid Crystal Model
HR236WU1-300(BOE)
ZD-238MT3C-V1
Resolution 1920×1080
Contrast 1000∶1
Brightness 250cd/m2
Bonding Method KT/QT
Driver Board 2513V2.1
Key Functions Support
Operating Temperature 0°-60°
Exterior Dimensions
ZD-238MT5C-V1
Resolution 1920×1080
Contrast 3000∶1
Brightness 250cd/m2
Bonding Method KT/QT
Driver Board 2513V2.1
Key Functions Support
Operating Temperature 0°-60°
Exterior Dimensions
Liquid Crystal Model M238HVN01.0
ZD-270MT2C-V1
Resolution 1920×1080
Contrast 3000∶1
Brightness 300cd/m2
Bonding Method KT/QT
Driver Board 2513V2.1
Key Functions Support
Operating Temperature 0°-60°
Exterior Dimensions
ZD-270MT5C-V1
Resolution 1920×1080
Contrast 3000∶1
Brightness 300cd/m2
Bonding Method KT/QT
Driver Board 2513V2.1
Key Functions Support
Operating Temperature 0°-60°
Exterior Dimensions
ZD-315MN1G-V3
Resolution 1920×1080
Contrast 1000∶1
Brightness 300cd/m2
Bonding Method KT/QT
Driver Board 2513V2.1
Key Functions Support
Operating Temperature 0°-60°
Exterior Dimensions
ZD-315MT1C-V1
Resolution 1920×1080
Contrast 1000∶1
Brightness 350cd/m2
Bonding Method KT/QT
Driver Board 2513V2.1
Key Functions Support
Operating Temperature 0°-60°
Exterior Dimensions
Liquid Crystal Model
LC320EUN-SFM1
ZD-315MT1C-V3
Resolution 1920×1080
Contrast 1000∶1
Brightness 300cd/m2
Bonding Method KT/QT
Driver Board 2513V2.1
Key Functions Support
Operating Temperature 0°-60°
Exterior Dimensions
ZD-430MT1C-V1
Resolution 1920×1080
Contrast 1200∶1
Brightness 300cd/m2
Bonding Method KT/QT
Driver Board 2513V2.1
Key Functions Support
Operating Temperature 0°-60°
Exterior Dimensions
Liquid Crystal Model
KW430EUN-SEM1(Assembled panel)
ZD-490MT2C-V1
Resolution 1920×1080
Contrast 1100∶1
Brightness 900cd/m2
Bonding Method KT/QT
Driver Board 2513V2.1
Key Functions Support
Operating Temperature 0°-60°
Exterior Dimensions
Liquid Crystal Model
LC490DUY-SHA2(4K:900Brightness)
ZD-550MT2C-V1
Resolution 3840×2160
Contrast 1100∶1
Brightness 600cd/m2
Bonding Method KT/QT
Driver Board 2513V2.1
Key Functions Support
Operating Temperature 0°-60°
Exterior Dimensions
Liquid Crystal Model
LD550EGE-FHM1(4K)
ZD-650MT2C-V1
Resolution 3840×2160
Contrast 1100∶1
Brightness 600cd/m2
Bonding Method KT/QT
Driver Board 2513V2.1
Key Functions Support
Operating Temperature 0°-60°
Exterior Dimensions
Liquid Crystal Model
LD650EGE-FHM1(4K)
